Home > Smarthome > Dimming and Lighting control
HAI Lighting control 220volts

Lighting Control for the 220V, 50Hz Markets!



(Demo Video Coming Soon!)

With HAI's Omni-Bus Lighting Network you can experience all of the benefits of a sophisticated lighting control system. Lighting control can enhance the enjoyment and value of your home, add security for peace of mind, and contribute to savings on your energy bill.


How HAI Omni-Bus Works
Power modules feed power to dimmer or non-dimming switches. Each switch wires to a DIN rail module. The power for the circuit also goes to these DIN rail modules, thus switches are not directly wired to lights but rather to the modules controlling the lights. As with third-party solutions, Omni-Bus lighting works by a low voltage wire from the hardwired switch to the dimmer DIN rail module, but with the distinctive advantage of being an HAI product.
Sophisticated lighting control
Integrating with an HAI Home Control System
Omni-Bus Products work as stand-alone or with an HAI Home Control System.
An HAI home control system has the ability to change your light settings by the time of day, a set schedule, by the triggering of events (including motion), via a telephone call, Touchscreen, Smartphone, or by a computer connected to the Internet.
The Home Lighting Control Alliance says that dimming your lights by 25% saves 20% of the energy used and extends bulb life by 10 times. Dimming your lights by 50% saves 40% in energy and extends bulb life by 20 times. HAI systems can automatically set lights to any percentage, saving you money every time a light is turned on.
Your HAI system can automatically turn off all of the lights in the house when you leave in order to lower your electric bill.



Omni-Bus Interface Translator Din Rail
HAI Part Number: 117A00-1
Omni-Bus 400W Dimmer Din Rail
The "gateway" of the Omni-Bus system, this devlice allows HAI Controllers (OmniLT, Omni IIe, OmniPro II, Lumina, and Lumina Pro) to interface with an Omni-Bus lighting network.
Required Omni-Bus component designed for International markets that use 220-240V~, 50Hz.

Omni-Bus Power Supply 2.5A Din Rail
HAI Part Number: 123A00-1

Omni-Bus Power Supply 2.5A Din Rail
24VDC 2.5A power supply; provides power to the Omni-Bus network
Required Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus Power Supply Interface 2A Din Rail
HAI Part Number: 124A00-1

Omni-Bus Power Supply Interface 2A Din Rail
Used to detect overloading and select cabling errors on the Omni-Bus network.
Required Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus Splitter Box 8-Way Din Rail
HAI Part Number: 120A00-1

Omni-Bus Splitter Box 8-Way Din Rail
Split one Cat-5 into eight. Used where a T-junction or network split is required; a splitter is required.
Required Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus Termination Plug
HAI Part Number: 122A00-1

Omni-Bus Termination Plug
Used to terminate the Omni-Bus network; each network must contain ONE and only one network Termination Plug.
Required Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus Jumper Plugs
HAI Part Number: 121A00-1

Omni-Bus Jumper Plug
Sold in packs of 10; used to terminate any open ends or open connectors on the Omni-Bus network.
Required Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus RF Transceiver Din Rail
HAI Part Number: 115A00-1
Omni-Bus RF Transceiver Din Rail
Wireless transceiver; use with Remote Control 113A00-2, 113A00-4, 113A00-7, 125A00-1, 125A00-2.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz.

Omni-Bus DALI Din Rail
HAI Part Number: 118A00-1

Omni-Bus DALI Din Rail
Controls DALI output devices; includes On/Off switching, Dimming, DALI group control, DALI broadcast control, and DALI scene control.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus USB Programming Interface Unit
HAI Part Number: 116A00-1

Omni-Bus Power Supply Interface 2A Din Rail
Configure and maintain all user programmable parameters of the Omni-Bus network with a PC. Includes Omni-Bus PC license.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz


Omni-Bus 3-Way Splitter
HAI Part Number: 119A00-1

Omni-Bus Splitter Box 8-Way Din Rail
3-Way Splitter; used where a T-junction or network split is required; a splitter is required.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus 400W Dimmer Din Rail
HAI Part Number: 110A00-1
Omni-Bus 400W Dimmer Din Rail
Controls 220V incandescent, 220V halogen, and low voltage transformers suitable for trailing edge dimming.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz.


Omni-Bus 900W Dimmer Din Rail
HAI Part Number: 110A00-2

Omni-Bus 900W Dimmer Din Rail
Controls 220V incandescent, 220V Halogen, low voltage electronic transformers, and low voltage magnetic transformers. Includes jumper to create leading edge to control rope lighting, track lighting, LED.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus 3000W Power Switch Din Rail
HAI Part Number: 111A00-1

Omni-Bus 3000W Power Switch Din Rail
Controls general purpose resistive including motors, flourescent lighting, and ceiling fans: 3000W (13A) @ 230V~, Motor: 4HP (3000W) @ 230V~, Ballast (Fluorescent lights): 3000W @ 230V~, Low Voltage Transformer: 3000W @ 230V~.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus 4-Channel Relay Module Din Rail
HAI Part Number: 112A00-1

Omni-Bus 4-Channel Relay Module Din Rail
Controls up to 4 general purpose resistive loads including irrigation valves, gates, doors, and lighting up to 460W: 460W (2A) @ 230V~ or for general purpose low voltage switching applications.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus 1-Button Wall Switch - White
HAI Part Number: 114A00-1

Omni-Bus 1-Button Wall Switch - White
Connects up to (6) third-party switches to the Omni-Bus network and has 6 LED outputs to control 2-lead bi-color or single color LED indicators for each switch.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz



Omni-Bus 1-Button Wall Switch - White
HAI Part Number: 113A00-1

Omni-Bus 1-Button Wall Switch - White
1-Button hardwired switch; controls dimmer, power switch, relay, or input into HAI controller.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus 1-Channel Wall Mount Remote Control - White
HAI Part Number: 113A00-2

Omni-Bus 1-Channel Wall Mount Remote Control - White
1-Button wireless switch; controls dimmer, power switch, relay, or input into HAI controller; requires 116A00-1 RF Transceiver.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus 2-Channel Wall Mount Remote Control - White
HAI Part Number: 113A00-4

Omni-Bus 2-Channel Wall Mount Remote Control - White
2 Button wireless switch; controls dimmers, power switches, relays, or inputs into HAI controller; requires 116A00-1 RF Transceiver.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus 3-Button Wall Switch - White
HAI Part Number: 113A00-5

Omni-Bus 3-Button Wall Switch - White
3- Button hardwired switch; controls dimmers, power switches, relays, or inputs into HAI controller.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz

Omni-Bus 6-Button Wall Switch - White
HAI Part Number: 113A00-8

Omni-Bus 6-Button Wall Switch - White
6-Button hardwired switch; controls dimmers, power switches, relays, or inputs into HAI controller.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz
Omni-Bus 6-Button Wall Switch - Brushed Stainless
HAI Part Number: 113A00-9

Omni-Bus 6-Button Wall Switch - Brushed Stainless
6-Button hardwired switch; brushed stainless steel; controls dimmers, power switches, relays, or inputs into HAI controller.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz
Keyfob Remote Control, 16 Channel
HAI Part Number: 125A00-2


Keyfob Remote Control, 16 Channel
Controls dimmer, power switch, relay, or inputs into HAI controller. 16-Channel Wireless RF transmitter; keyfob, requires 116A00-1 RF Transceiver.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz
Keyfob Remote Control, 6 Channel
HAI Part Number: 125A00-1


Keyfob Remote Control, 6 Channel
Controls dimmer, power switch, relay, or inputs into HAI controller. 6-Channel Wireless RF transmitter; keyfob, requires 116A00-1 RF Transceiver.
Omni-Bus component designed for International markets that use 220-240V~, 50Hz
